Category: Step-Down

The compact (0.4″ × 0.5″) D24V5F6 synchronous buck voltage regulator takes an input voltage of up to 36 V and efficiently reduces it to 6 V while allowing for a maximum output current of 500 mA. Pololu 2844

Step-Down RT8272 converter with adjustable output voltage in the range from 5 V to 12 V, input voltage from 5 to 24 V and a maximum output current of 3 A

DC-DC Step-Up converter U3V40F7 with an output voltage of 7.5 V, an input voltage of 1.3 to 7.5 V and a maximum output current of 4 A. Pololu 4014

Step-Down DC-DC converter module based on the D36V6F5 chip. Input voltage 5.2..50V, output voltage 5V (max. 600mA). Pololu 3792

An efficient step-down converter that steps down the input voltage from as low as 45 V to a regulated output voltage range of 1.4 to 7 V, offering high efficiency and a maximum continuous current of 3.8 A. It has built-in reverse polarity, overload and short circuit protection, and the spread spectrum function reduces EMI interference. Pololu 4853

The compact (0.4″ × 0.5″) D24V5F1 synchronous buck voltage regulator takes input voltages between 3 V and 36 V and efficiently reduces them to 1.8 V while allowing for a maximum output current of 500 mA. This regulator offers typical efficiencies between 75% and 90%. The pins have a 0.1″ spacing, making this board compatible with standard solderless breadboards and perfboards.

DC-DC step-down converter module 12V 12A used to convert energy from 15-24V input voltage to stable 12V, providing up to 12A current. Thanks to high conversion efficiency (over 90%) and low ripple (<50mV), it is ideal for powering sensitive devices in applications such as robotics, drones or LED lighting systems. Additionally, built-in overheating and short-circuit protection mechanisms ensure reliable operation even in difficult conditions. DFRobot DFR1208

Step-Down converter D36V50F5 with an output voltage of 5 V, an input voltage from 5.5 to 50 V and a maximum output current of 8 A. Pololu 4091

The compact (0.4″ × 0.5″) D24V5F5 synchronous buck voltage regulator takes an input voltage of up to 36 V and efficiently reduces it to 5 V while allowing for a maximum output current of 500 mA. Pololu 2843

This small synchronous switching step-down (or buck) regulator takes an input voltage of up to 36V and efficiently reduces it to 5V. The board measures only 0.7″ × 0.7″ yet delivers a typical continuous output current of up to 2.5A and features reverse voltage protection. Pololu 2858

Step-Down converter D36V28F12 with an output voltage of 12 V, an input voltage from 12.9 to 50 V and a maximum output current of 3.3 A. Pololu 3786

Step-down voltage regulator module based on the APM81815 providing a fixed 5.35 V output at up to 1.1 A with an input voltage range of 5.4 - 72 V. Pololu 5268

DC-DC step-down converter module 5V 16A used to convert energy from 6-24V input voltage to stable 5V, providing up to 16A current. Thanks to high conversion efficiency (over 90%) and low ripple (<20mV), it is ideal for powering sensitive devices in applications such as robotics, drones or LED lighting systems. Additionally, built-in overheating and short-circuit protection mechanisms ensure reliable operation even in difficult conditions. DFRobot DFR1202

Step-down DC-DC converter module that converts a 12 V or 11.1 V output voltage (e.g. from a lithium battery) to a voltage in the range of 1.8 V to 5.1 V. It has a power output of up to 60 W, and with an output current of up to 18 A, the module can be used to power a 5 m WS2812 RGB LED strip. DFRobot DFR1025

An efficient step-down converter that reduces the input voltage to 5 V at a maximum current of 100 mA, offering high efficiency due to low quiescent current (<20 μA). It supports input voltages from 5 V to 65 V, has short circuit and overheating protection, making it a reliable and energy-efficient solution. Pololu 5363

Step-Down DC-DC converter module based on the D36V6F12 system. Input voltage 12.2.50V, output voltage 12V (max. 600mA). Pololu 3796

An efficient step-down converter that steps down the input voltage from as low as 45 V to a regulated output voltage range of 1.4 to 7 V, offering high efficiency and a maximum continuous current of 3.4 A. It has built-in reverse polarity, overload and short circuit protection, and the spread spectrum function reduces EMI interference. Pololu 4873

Efficient step-down converter that reduces the input voltage from up to 45 V to a regulated output voltage range from 1.4 to 7 V, offering high efficiency and a maximum continuous current of 3.4 A. It has built-in protection against reverse polarity, overload and short circuit, and the spread spectrum function reduces EMI interference. The module is equipped with an additional potentiometer for adjusting the cut-off voltage. Pololu 4872

Step-Down converter D36V28F7 with an output voltage of 7.5 V, an input voltage from 8 to 50 V and a maximum output current of 3.7 A. Pololu 3784

An efficient step-down converter that reduces the input voltage to 12 V at a maximum current of 100 mA, offering high efficiency thanks to low quiescent current (<50 μA). It supports input voltages from 12 V to 65 V, has short circuit and overheating protection, making it a reliable and energy-efficient solution. Pololu 5367
