ESP32-S3-LCD-2-C is an integrated development board with a 2" display and an included OV5640 camera, combining display, wireless connectivity, and video acquisition functions in a single module. Thanks to support for an accelerometer, TF card slot, USB-C power supply, and extensive GPIO interfaces, the board is suitable for applications such as portable monitoring systems, image recording, and interactive IoT projects.

24h
Available
Available quantity: 2
Kamami is the official distributor of Waveshare displays, accessories and modules.

Description

The ESP32-S3-LCD-2-C is a compact development board based on the ESP32-S3R8 microcontroller, equipped with a 2-inch color IPS display with a resolution of 240×320 px, controlled by the ST7789T3 driver via the SPI interface. The device integrates a dual-core Xtensa LX7 processor running up to 240 MHz, 2.4 GHz Wi-Fi, Bluetooth 5 LE, and a built-in antenna. The "-C" version includes an OV5640 camera (5 MP), which can be used for image capture and video recording. The board also features a 6-axis QMI8658 sensor (accelerometer + gyroscope), TF card slot, 3.7 V lithium battery connector, and USB Type-C port for power and programming. The module supports ESP-IDF and Arduino IDE, making it a versatile tool for AIoT projects, monitoring, and image data acquisition.

Specifications

  • Processor: Xtensa 32-bit LX7 dual-core, up to 240 MHz
  • Connectivity: Wi-Fi 2.4 GHz (802.11 b/g/n), Bluetooth 5 LE
  • Memory: 512 KB SRAM, 384 KB ROM, 8 MB PSRAM, 16 MB Flash
  • Display: IPS 2", 240×320 resolution, 262K colors, ST7789T3 controller, SPI interface
  • Camera: OV5640 (5 MP) for image and video capture
  • Sensor: QMI8658 – 3-axis accelerometer and gyroscope
  • TF card slot for storing images and files
  • USB Type-C port for power, programming, and debugging
  • Battery connector: MX1.25 for 3.7 V lithium battery
  • GPIO: 22 available pins for custom configurations
  • Software support: ESP-IDF and Arduino IDE
  • Package Includes
  • ESP32-S3-LCD-2 x1
  • OV5640 camera module x1
