Small motor with metal gear and encoder, rotation speed 150 RPM, operating voltage 6 V. GA46-N20E-0046
free shipping in Poland for all orders over 500 PLN
If your payment will be credited to our account by 11:00
Each consumer can return the purchased goods within 14 days
A small motor with a metal gearing with a D-shaped shaft, 3 mm in diameter and approx. 10 mm long. The motor is equipped with an incremental encoder. The recommended operating voltage of the motor is 6 V and at this voltage it achieves a speed of 150 RPM and a maximum torque of 1,1 kg * cm, consuming a current from 0.054 A to 0.59 A.
Recommended supply voltage for motors is 6 V, but the motors operate without problems in the range from 3 V to 9 V. It is possible to supply the motor with higher voltage, but it reduces the service life of the motor.
All N20E motors have the same dimensions. The metal gear housing has two tapped holes for M1.6 bolts (1.6mm diameter, 0.35mm pitch). The engines weigh approx. 14 g.
![]() |
Dimensions of N20E micromotors (units in mm). |
---|
Our offer includes N20E motors with gear ratios from 10: 1 to 380: 1.
Gear ratio | Type | Voltage | Rotation speed | max. torque | min. current | max. current | Link |
10:1 | MP | 6 V | 2000 RPM | 0,08 kg*cm | 54 mA | 0,59 A | LINK |
15:1 | MP | 6 V | 1000 RPM | 0,11 kg*cm | 54 mA | 0,59 A | LINK |
30:1 | MP | 6 V | 500 RPM | 0,22 kg*cm | 54 mA | 0,59 A | LINK |
50:1 | MP | 6 V | 300 RPM | 0,36 kg*cm | 54 mA | 0,59 A | LINK |
100:1 | MP | 6 V | 200 RPM | 0,8 kg*cm | 54 mA | 0,59 A | LINK |
150:1 | MP | 6 V | 150 RPM | 1,1 kg*cm | 54 mA | 0,59 A | LINK |
200:1 | MP | 6 V | 100 RPM | 1,4 kg*cm | 54 mA | 0,59 A | LINK |
250:1 | MP | 6 V | 60 RPM | 1,7 kg*cm | 54 mA | 0,59 A | LINK |
298:1 | MP | 6 V | 50 RPM | 2,0 kg*cm | 54 mA | 0,59 A | LINK |
380:1 | MP | 6 V | 30 RPM | 2,5 kg*cm | 54 mA | 0,59 A | LINK |
Our offer includes wheels suitable for motors with a shaft with a diameter of 3 mm and the shape of the letter "D". There are wheels of various diameters from 32 mm to 90 mm in many colors.
![]() |
![]() |
![]() |
Pololu 32x7mm wheels (black) | Pololu 32x7mm wheels (white) | Pololu 40x7mm wheels (red) |
![]() |
A list of Pololu wheels with different diameters available in the following colors: white, blue, red, yellow and black |
The silicone tracks to match the Pololu miniature motors are available in two lengths: 22T (48mm) and 30T (85mm) and three colors: white, black and red.
![]() |
![]() |
![]() |
Pololu 22T track set (black) | Pololu 22T track set (red) | Pololu 30T track set (white) |
Specially designed brackets matching the miniature Pololu engines will also work well when mounting N20 engines. They are available in two colors: white and black, and in a standard and extended version.
![]() |
![]() |
![]() |
Pololu Miniature Motor Bracket (Black) | Pololu Miniature Motor Bracket Pololu (White) | Pololu Miniature Motor Bracket extended (White) |
It is not possible to control the motors directly from the microcontroller ports due to the high power consumption. This problem is solved by the motor drivers. Thanks to the controllers, it is possible not only to turn on and only the motors, but also to control their speed and direction of rotation.
Our offer includes a number of drivers for one or two motors. The drivers are available in the form of modules, shield extensions for Arduino and hat extensions for Raspberry Pi.
![]() |
![]() |
![]() |
DC motor controller with DRV8838 Pololu | Shield Arduino with dual driver for DC motors with A4990 chip | Dual driver for DC motors with DRV8835 chip |
Current sensors measure how much current the motors are consuming at a given moment, which allows to determine the load on the motors. Our offer includes sensors with measuring ranges from ± 5 to ± 75.
![]() |
![]() |
![]() |
Current sensor module 0-5A with ACS712-05 chip | Current sensor module ± 5A with ACS714 chip | Current sensor module ± 15.5A with ACS711EX system |
A small medium-power motor with a 30:1 metal gear, 6 V operating voltage, 0.04 A to 0.67 A power consumption, 720 RPM, a maximum torque of 0.33 kg*cm and a double-sided shaft. Pololu 2378
No product available!
A small, high-power motor with a 250: 1 metal gear, 6 V operating voltage, 0.1 A to 1.5 A power consumption, 130 RPM, a maximum torque of 3.2 kg * cm and carbon brushes with increased durability. Pololu 3068
No product available!
Small metal gear motor, 100 RPM speed, 12V operating voltage. GA12-N20-0023
A small, high power motor with a 50: 1 metal gear, 12 V operating voltage, 0.06 A to 0.75 A power consumption, 650 RPM speed, maximum torque of 0.67 kg * cm and carbon brushes with increased durability. Pololu 3039
No product available!
Small motor with metal gear and encoder, rotation speed 2000 RPM, operating voltage 6 V. GA46-N20E-0051
Small motor with metal gear and encoder, rotation speed 100 RPM, operating voltage 6 V. GA46-N20E-0045
No product available!
A small, low-power motor with a 380: 1 metal gear, 6 V operating voltage, 0.02 A to 0.36 A power consumption, 36 RPM speed, maximum torque of 2.9 kg * cm and double-sided shaft. Pololu 4791
No product available!
A small, low-power motor with a 210:1 metal gear, 6 V operating voltage, 0.02 A to 0.36 A current consumption, 65 RPM, a maximum torque of 1.6 kg*cm and a double-sided shaft. Pololu 2206
No product available!
Small metal gear motor, 200 RPM speed, 3V operating voltage. GA12-N20-0006
Miniature high-power motor from the Pololu MP series. The 210: 1 gear motor, shaft speed is 100 rpm, the torque is 2.6 kg * cm (0.26 Nm). The motor has an extended shaft which makes it easy to attach the encoder. Pololu 2383
No product available!
Miniature high-power motor from the Pololu MP series. 100: 1 gear motor,
the rotation speed of the shaft is 220 rpm, the torque is 1.5 kg * cm (0.15 Nm).
The motor has an extended shaft which makes it easy to attach the encoder. Pololu 2381
Small metal gear motor, 60 RPM speed, 12V operating voltage. GA12-N20-0022
A small, powerful motor with 5:1 metal gear, 6 V operating voltage, 0.07 A to 1.6 A power consumption, 6100 RPM, maximum torque of 0.11 kg*cm and double-sided shaft. Pololu 2210
No product available!
This gearmotor is a miniature high-power, 6 V brushed DC motor with a 986.41:1 metal gearbox, making it a great choice for applications requiring fine control at very low speeds. It has a cross section of 10 × 12 mm, and the D-shaped gearbox output shaft is 9 mm long and 3 mm in diameter. This version also has a 4.5 × 1 mm extended motor shaft.
No product available!
This gearmotor is a miniature high-power, 6 V brushed DC motor with long-life carbon brushes and a 248.98:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped gearbox output shaft is 9 mm long and 3 mm in diameter. This version also has a 4.5 × 1 mm extended motor shaft.
This gearmotor is a miniature medium-power, 6 V brushed DC motor with a 75.81:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped gearbox output shaft is 9 mm long and 3 mm in diameter. This version also has a 4.5 × 1 mm extended motor shaft.
Key specs at 6 V: 290 RPM and 40 mA with no load, 17 oz-in (1.2 kg-cm) and 0.7 A at stall.
