ACP1000 - AC current probe for Micsig oscilloscopes
ID: 1182403
5906623436934
zł1,199.03
Tax included
zł974.82 tax excl.
Probe for measuring AC currents up to 1000 A. It works in the range from 10 Hz to 100 kHz, it can be connected to the oscilloscope through the BNC connector. Micsig ACP1000
Description
Probe for measuring AC currents up to 1000 A. Uses standard BNC interface and can be connected to an oscilloscope or a multimeter. It works in the frequency range from 10 Hz to 100 kHz, has three measuring ranges: 10, 100 and 1000 A. The jaw spacing allows you to measure the current flowing in cables with a maximum diameter of 52 mm. It can be used in industry, automotive electronics, power supplies and inverters. Dedicated to Micsig devices.
Features
- Bandwidth: 10 Hz to 100 kHz
- Measurement range:
- 0.1 A to 10 A, 100 mV/A, 3% ± 10 mV
- 0.1 A to 100 A, 10 mV/A, 2% ± 5 mV
- 1 A to 1000 A, 1 mV/A, 1% ± 1mV
- Output signal: mV/A
- Maximum measured current: 2000 A.
- Maximum working voltage: CAT ⅡI 600V
- Maximum cable diameter: 52 mm
- BNC connector
- Cable length: 1.5 m
- Working temperature: from -15°C to 75°C
- Dimensions: 111 x 216 x 45 mm
1182403
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
