24V, 8A Step-Down Voltage Regulator D42V110F24
ID: 1201572
5902186330740
zł220.12
Tax included
zł178.96 tax excl.
The step-down converter module allows you to reduce the voltage from 24-60 V to a stable 24 V at a current of up to 8 A. High efficiency of up to 95% and low power losses make it ideal for applications requiring high current and stable power. The device has built-in overcurrent, thermal, and reverse connection protection, as well as a soft-start function and a Power Good indication. Pololu 5684
Description
Step-down (buck) converter module designed to reduce an input voltage from 24 V to 60 V down to a regulated 24 V output with a current of up to 8 A. This is a synchronous switching converter, providing high efficiency (up to 95%) and significantly lower power losses compared to traditional linear regulators. It is ideal for systems requiring high current and stable power supply, such as microcontroller circuits, motor power systems, automation, or advanced hobby projects.
The device is equipped with multiple protections, including reverse voltage protection, overcurrent protection, and thermal shutdown in case of overheating. Additionally, the built-in soft-start function limits inrush current, ensuring a smooth rise of output voltage at startup. The module also offers an ENA input for enabling/disabling the circuit and a Power Good (PG) output that indicates correct output voltage and can be used to monitor power status.
The module features a low quiescent current (<0.3 mA) and a high switching frequency of about 800 kHz, allowing the use of small filtering components. With its compact dimensions and four mounting holes, the regulator can be easily installed in almost any project. The board includes convenient solder pads for connecting power wires or 5 mm screw terminals. Thanks to its wide input voltage range and high output power, the converter provides a reliable source of stable power in systems that require low voltage, high current, and excellent energy efficiency.
Features
- D42V110F24 step-down (buck) converter
- Input voltage: 24 V – 60 V
- Output voltage: 24 V ±3%
- Maximum output current: 8 A (typical at 42 V input)
- Efficiency: 80–95% depending on load
- Switching frequency: approx. 800 kHz
- Quiescent current: < 0.3 mA (typical)
- ENA input: allows load disconnection and low-power mode
- Power Good (PG) output: indicates correct output voltage
- Operating modes: PFM/FPWM – switched depending on load
- Protections: overcurrent, thermal, short-circuit, and reverse voltage
- Soft-start function: gradual voltage ramp-up at startup
- Dimensions: 31.8 × 43.2 × 9 mm
- Mounting: 4 mounting holes Ø 2.2 mm
- Weight: 15 g
1201572
Data sheet
- Output voltage
- 24V
- Output current
- 8 A
- Converter type
- Step-down
- Supply voltage min
- 24 V
- Supply voltages max
- 60 V
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
