MD10C DC Motor Driver 10A 5V-30V - DC motor controller
ID: 578524
5906623405343
zł62.04
Tax included
zł50.44 tax excl.
DC motor driver with a working voltage from 5 to 30 V and a maximum continuous current of 13 A. It can be controlled by a PWM signal or by means of built-in buttons. Cytron MD10C
Description
Single-channel DC motor driver. It allows you to control the movement of motors with a supply voltage from 5 to 30 V and a current consumption of up to 13 A (continuous current), and even 30 A (instantaneous current). The control can be done via the PWM signal or using the built-in buttons, which allow very easy testing of the drives without the need to connect a controller. The driver uses components that ensure faster response times. The module can work with 3.3 V and 5 V systems, making it compatible with all popular development boards. In the GitHub repository, the Arduino library is available along with the user manual.
Features
- Single-channel DC motor driver
- The motor supply voltage is from 5 V to 30 V
- Maximum continuous current up to 13 A and temporary 30 A (10 seconds)
- Control voltage 3.3 V or 5 V
- The components used ensure a quick reaction time
- It does not require a heat sink
- Screw connection for power and motor connection
- Control buttons
- 3-pin control connector (DIR, PWM, GND)
- Speed control by PWM signal up to 20 kHz
- Dimensions: 75 x 43 mm
Kit contains
- DC motor driver MD10C R3.0 10A
- PCB connector 2510 3-pin (female)
- 3 x Clamp Pins 2510
- 4 x 7mm plastic spacer
578524
Data sheet
- Output current
- 13 A
- Number of channels
- 1
- Supply voltage min
- 5 V
- Supply voltages max
- 30 V
