CM4-IO-BASE-BOX-A kit for building mini PC with Raspberry Pi CM4 - Waveshare 20258
ID: 586580
5906623469482
zł163.28
Tax included
zł132.75 tax excl.
A set for building a minicomputer based on Raspberry Pi CM4. It consists of a metal housing with a fan, a power supply and a Mini Base Board (A). Waveshare CM4-IO-BASE-BOX-A
Description
A set for building a minicomputer based on Raspberry Pi CM4 modules. It consists of a metal housing with a fan, a power supply and a Compute Module 4 Base Board (A).
Compute Module 4 IO Base Board (A) is equipped with special connectors for connecting the module and outputs of all CM4 module interfaces, including USB, Ethernet, HDMI, DSI, two CSI connectors, 40-Pin GPIO connector compatible with HAT modules. The Mini Base Board is additionally equipped with a fan connector and a microSD card slot. At the bottom of the board there is also an M.2 connector for connecting additional modules or a disk and an FFC connector with a USB 2.0 and HDMI interface.
The metal case has openings for all connectors and a fan cutout, which ensures better cooling of the system. It is equipped with numerous holes for easy mounting, for example on the wall.
Features
- Compute Module 4 Base Board (A)
- CM4 connector: suitable for all variants of the Raspberry Pi CM4 module (not included)
- Standard 40-pin Raspberry Pi HAT connector
- HDMI connector
- 2 x CSI camera connector
- DSI Display Connectors
- RJ45 Gigabit Ethernet connector
- Built-in USB Hub with 2 USB 2.0 connectors
- USB type C connector for power and programming
- MicroSD card slot
- 5V fan connector
- Power supply: USB type C
- Dimensions: 85 x 56 mm
- Holes for all board connectors
- Fan cutout (fan included)
- Multiple mounting holes
- 5V 3A USB Type-C power adapter
- Dimensions: 88.1 x 99.8 x 33 mm
Kit contains
- Case (two parts)
- Compute Module 4 IO Base Board (A) (without Raspberry Pi CM4 module)
- Screwdriver
- Fan-4010-PWM-12V fan
- A set of screws
- USB Type-C 5V 3A power supply
