KAmodRPi UART RS485 ISO Transceiver RS485 with Galvanic Isolation for Raspberry Pi
ID: 1187255
5906623433384
zł67.70
Tax included
zł55.04 tax excl.
The KAmodRPi UART RS485 ISO is an advanced RS485 bus transceiver for the Raspberry Pi, featuring automatic transmission direction control, galvanic isolation, surge protection, and support for up to 128 modules at a transmission speed of up to 500 kbps, powered by 5V with low power consumption
Description
The KAmodRPi UART RS485 ISO is an RS485 bus transceiver controlled from a UART interface, compatible with the Raspberry Pi SBC family. On the RS485 bus side, the MAX13487 chip is used, which features automatic transmission direction control. This solution requires only 2 signals - RXD and TXD for proper, two-way communication using the standard UART interface. The control signals are connected through circuits providing galvanic separation. Additionally, the module is equipped with surge protection on the RS485 bus lines and allows the connection of a 120 Ω resistance serving as a terminator for the RS485 bus.
Features
- RS485 bus transceiver module controlled from a UART interface
- RS485 bus transceiver type MAX13487
- Automatic switching between transmitting/receiving data
- Only 2 signals RXD and TXD required for proper two-way communication (TX ENABLE signal not required)
- Half-duplex communication
- Transmission speed - max 500 kbps
- Number of modules that can be attached to the bus - max 128
- Independent power supply for RXD and TXD line circuits, allowing cooperation with systems operating at 2.0-5.5 V (no additional voltage translators required)
- Transmit/receive data indication - LED diodes
- Included 120 Ω resistance (RS485 bus terminator)
- Option to block data reception (RXD signal blocking)
- Galvanic separation up to 1 kV
- Surge protection on RS485 bus lines
- RS485 bus connector type Phoenix Contact MC 3.81 mm
- 5 V power supply through a connector in RPi Zero standard or goldpin headers
- Maximum current consumption 100 mA
- Operating temperature: -40°C ~ 85°C
- Board and connector in Raspberry Pi Zero standard
- Dimensions: 65 mm x 30 mm x 20 mm
Included in the set
- KAmodRPi UART RS485 ISO module
- Set of screws and spacers for mounting the overlay on the Raspberry Pi board
1187255
Data sheet
- Compatible with
- Raspberry Pi 5/4/3/2/1 A/B, Zero/Zero 2 H/WH
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
