zł27.69 tax excl.
Module with ACHS-7123 current sensor with a measuring range of direct and alternating current from -30 to 30 A. It communicates via an analog interface. Pololu 4032
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with a bidirectional Hall current sensor based on the ACHS-7123 system. It allows you to measure the current in the range from -30 to 30 A. The board is powered with the voltage from 4.5 V to 5.5 V and is intended for use in circuits with a logical voltage of 5 V. It offers a current path with low resistance (~ 0,7 mΩ) and electrical insulation up to 3 kV RMS. The output is a proportional analog voltage (66 mV/A) centered at 2.5 V with an error of ± 1.5%.
The sensor requires five connections to work properly: input current (IP+ and IP-), logic power (VCC and GND) and sensor output (OUT). Pin FILTER allows you to adjust the bandwidth of the plate by adding a capacitor to ground in parallel with the 1 nF capacitor that is already on the board. Without an additional external filter capacitor, the frequency response is approximately 80 kHz.
Features
- Hall effect differential detection
- The internal resistance of the conductive path is 0.7 mΩ
- Electrical insulation up to 3 kV RMS
- High bandwidth up to 80kHz for fast response times
- Integrated digital temperature compensation circuit
- The rugged sensor IC can tolerate 100 ms to 100 A transient currents
- Operating voltage 4.5 to 5.5 V
- Current measuring range from -30 to 30 A
- Output resolution 0.066 V/A
- Operating temperature range from -40°C to 110°C
- Dimensions: 17.8 x 20.3 mm
- Weight: 1.1 g
Kit contains
- ACHS-7123 Current Sensor Carrier module
- Straight 3-pin male connector
