ESP32-S3-Touch-LCD-2.1
search
  • ESP32-S3-Touch-LCD-2.1
  • ESP32-S3-Touch-LCD-2.1
  • ESP32-S3-Touch-LCD-2.1
  • ESP32-S3-Touch-LCD-2.1
ID: 1197421
zł155.05
Tax included

zł126.06 tax excl.

ESP32-S3-Touch-LCD-2.1 in the flat panel version is an advanced platform for developing interactive applications with a touch graphic interface. Thanks to its extensive feature set, including wireless connectivity, PSRAM memory, sensors, and battery power support, it is suitable for mobile devices, HMI interfaces, monitoring systems, and IoT projects.

4 weeks
Awaiting delivery
Kamami is the official distributor of Waveshare displays, accessories and modules.

Description

The ESP32-S3-Touch-LCD-2.1 is a compact development board featuring a dual-core ESP32-S3R8 microcontroller and an integrated 2.1-inch LCD touch display with a resolution of 480×480 px. It supports 2.4 GHz Wi-Fi and Bluetooth 5 LE, and is equipped with sensors, peripheral interfaces, TF card support, and battery power management. The flat capacitive touch panel enables intuitive interaction with a GUI based on LVGL. The board is designed for rapid prototyping of HMI applications, AIoT devices, and mobile projects.

Features

  • ESP32-S3R8 microcontroller with dual-core Xtensa LX7 processor, up to 240 MHz
  • 512 KB SRAM, 384 KB ROM, 8 MB PSRAM, and 16 MB Flash memory
  • 2.1" IPS display, 480×480 px resolution, 262K colors
  • Capacitive touch panel controlled via I2C (CST820 controller)
  • Wi-Fi 802.11 b/g/n and Bluetooth 5 LE support
  • USB Type-C port for power, programming, and UART communication
  • Integrated PCM5101 audio decoder, microphone, and buzzer
  • 6-axis QMI8658 sensor (accelerometer + gyroscope), RTC PCF85063
  • TF card slot and MX1.25 lithium battery connector
  • GPIO, UART, I2C headers, IPEX1 antenna interface
  • Compatible with ESP-IDF, Arduino, and MicroPython
  • Flat-panel touch version

Included

  • ESP32-S3-Touch-LCD-2.1 x1
  • SH1.0 12PIN cable (~100 mm) x1
  • SH1.0 4PIN cable (~100 mm, 2 pcs) x1
