PP-150 - oscilloscope probe x10 600V 100MHz
ID: 1183459
5906623408306
zł30.00
Tax included
zł24.39 tax excl.
A universal oscilloscope probe with a BNC connector and a 10:1 voltage divider. It has a frequency response of 100 MHz and allows measurements with a maximum voltage of up to 600 V. Hantek PP-150
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Universal oscilloscope probe with BNC connector, 10:1 voltage divider and 100 MHz frequency response. It allows you to make measurements with a maximum voltage of up to 600 V. The probe is terminated with a sharp tip on which a cap with a hook can be applied, while the ground wire has a crocodile connector. It can work with analog and digital oscilloscopes with a standard BNC connector.
Features
- Bandwidth:
- x1: 6 MHz
- x10: 100 MHz
- Maximum voltage:
- x1: 200 V DC + Peak AC
- x10: 600 V DC + Peak AC
- Attenuation: x1, x10
- Input impedance: 1 MΩ, 100 MΩ
- Input capacitance:
- x1: 85pF - 115pF
- x10: 18.5pF - 22.5pF
- Compensation range: 15 pF to 35 pF
- Cable length: 120 cm
- Operating temperature: -10 to 50°C
- Operating humidity: up to 85%
Kit contains
- Oscilloscope probe with BNC connector
- Measuring cap
- Set of color markers
