OP10000-1G - 10000X tip for 1GHz SigOFIT Micsig probe
ID: 1197274
5902186321236
zł7,629.76
Tax included
zł6,203.06 tax excl.
A probe tip with attenuation factor of 10000X. Dedicated to Micsig probes from the SigOFIT series operating in the 800 MHz and 1 GHz frequency band. Micsig OP10000-1G
Description
The 10000X attenuation probe tip is designed to extend the measurement range of Micsig high-frequency probes. It enables safe and accurate operation at high voltages, ensuring both safety and precision. With its low input impedance, it minimizes any influence on the measured signal. Fully compatible with OIP800 and OIP1000 probes, this tip is suitable for signal analysis up to 1 GHz in both laboratory and field applications. Its compact design makes it easy to access hard-to-reach measurement points.
Features
- Attenuation ratio: 10000:1 @0dB ±5000V, 1000:1 @20dB ±500V
- Maximum operating voltage: ±8000Vpp
- Input impedance: 40.82MΩ || 2.4pF
- Compatible with OIP800 and OIP1000 probes
- Adapter type: LCX
