zł21.06 tax excl.
Module with ethanol sensor made in MEMS technology. It allows gas detection in the range of 1 to 500 ppm and has an analog output. DFRobot SEN0569
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Ethanol sensor module that uses electromechanical microsystem (MEMS) technology, resulting in a compact sensor, low power consumption, short acquisition time and fast response. It can measure concentrations from 1 to 500 ppm and is suitable for generating leak alarms in, for example, portable gas detectors. The sensor has an analog output and is supplied with a voltage of 3.3 V to 5 V. Full documentation and sample programs are available on the product page.
Features
- Detected gas: EtOH
- Detection range: 1 to 500 ppm
- Output signal: analog
- Sensitivity: R0 (in air)/Rs (in 150ppm EtOH) ≥ 3
- Working temperature: -10 to 50℃
- Operating humidity: 15 to 90% RH (non-condensing)
- Lifespan: ≥5 years (in the air)
- Power supply: 3.3 to 5V
- Operating Current: <20mA
- Dimension: 13x13x2.5mm
Kit contains
- Fermion: MEMS Ethanol EtOH Gas Detection Sensor
- Goldpin male connector
Data sheet
- Interface
- Sygnał analogowy
- Type of sensor
- inny
- Power supply voltage
- 3,3 - 5 V
- Concentration measurement
- Alcohol
