New products
New products
zł27.05 tax excl.
Module with an analog MQ2 gas sensor. It enables the detection of LPG, butane, propane, methane, alcohol, hydrogen and smoke. It is powered with the voltage of 5 V and has an analog output. DFRobot SEN0127
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with an analog universal MQ2 gas sensor. It enables the detection of LPG, butane, propane, methane, alcohol, hydrogen and smoke. The module is powered with 5 V and has an analog output (Gravity connector) proportional to the measured concentration. The sensor is characterized by high sensitivity regulated by a potentiometer. The Wiki page contains the manual and sample programs.
Features
- Detection range:
- LPG and Propane: 20 to 5000 ppm
- Butane: 300 to 5000 ppm
- Methane: 5,000 to 20,000 ppm
- H2: 300 to 5000 ppm
- Alcohol: 100 to 2000 ppm
- Analog interface
- Quick reaction
- Adjustable sensitivity by potentiometer
- Stable performance
- Simple connection via the Gravity connector
- Power supply: 5V
- Size: 36.4 x 26.6mm
Kit contains
- Analog Gas Sensor (MQ2) Module
- Gravity cable
Data sheet
- Interface
- Sygnał analogowy
- Type of sensor
- MQ-2
- Power supply voltage
- 5 V
- Concentration measurement
- LPG
