KAmod CAN-TXRX is a CAN bus transceiver with the MCP2542FD system, compatible with the CAN 2.0 and CAN FD standards, enabling sending and reading data with the serial interface voltage level adjustable in the range of 1.7...5 V, equipped with protections and LEDs signaling action

24h
Available
Available quantity: 123


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

KAmod CAN-TXRX is a CAN bus transceiver with the MCP2542FD system. It allows you to send and read data from the CAN bus operating in the latest CAN 2.0 and CAN FD standards and includes a number of protections against damage. The module is not a CAN bus controller - it must receive appropriate data frames, compliant with the CAN standard, from the control system - e.g. a microcontroller. Communication with the module takes place via a serial interface with C-RX and C-TX signals. The voltage level of the serial interface can be set in the range of 1.7...5 V. The values of 5 V and 3 V can be easily selected using jumpers on the board, while a different, non-standard voltage value should be connected to the VIO pin. The transceiver module is equipped with diodes indicating correct power supply and communication.

Features

  • CAN bus transceiver, compatible with CAN 2.0 and CAN FD
  • It is based on the MCP2542FD system
  • Communication via serial interface with RX and TX signals
  • The voltage level of the serial interface can be set in the range of 1.7...5 V
  • Additional VIO input determining the voltage level of the serial interface
  • Communication speed (bit rate): 14.4 kbps...8 Mbps
  • Power supply 5V, 100mA
  • Attachable 120 Ω terminating resistor
  • LED diodes indicating correct power supply and communication
  • CAN bus lines connected via the Phoenix MC 3.81 mm connector
  • Plate dimensions 61x20 mm, height approx. 12 mm
