New products
zł39.51 tax excl.
Module with temperature, humidity and pressure sensor BME680 from Bosch. The module communicates via I2C or SPI interfaces.
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The BME680 sensor module is an integrated gas, pressure, temperature and humidity sensor placed in one MEMS housing. The system can be supplied with a voltage of 1.7-3.6 V. It is equipped with two communication interfaces: I2C and SPI. BME680 has been especially developed for mobile applications and wearables, where size and low energy consumption are key requirements.
The BME680 gas sensor can detect a wide range of gases for measuring air quality. Gases that BME680 can detect are volatile organic compounds (VOCs) from paints (such as formaldehyde), varnishes, paint strippers, cleaners, furniture, office equipment, adhesives, adhesives and alcohol.
Features
- Temperature measuring range: -40 to 85 ℃
- Temperature measuring accuracy: ± 1 ℃
- Air humidity measurement range: 0-100%
- Air humidity measurement accuracy: ± 3%
- Atmospheric pressure measuring range: 300-1100 hPa
- Accuracy of atmospheric pressure measurement: ± 0.6 hPa
- Air quality measurement range: 0-500 (the higher the value, the worse the air condition)
- Interface: I2C, SPI
- Power consumption: 3.7 uA (max)
- Supply voltage: 1.7 to 3.6 V
Kit contains
- Module with BME680 sensor
- Goldpin straight 6-pin connector
Data sheet
- Interface
- SPI/I2C
- Type of sensor
- BME680
- Power supply voltage
- 1.7..3.6V
- Concentration measurement
- VOC
- Sensor type
- Ciśnienia atmosferycznego
