Gravity: Geiger Counter - module with Geiger counter
ID: 1178727
5902186310261
zł265.21
Tax included
zł215.62 tax excl.
Module with a Geiger counter that allows the detection of ionizing radiation. Equipped with a Gravity connector. DFRobot SEN0463
Description
Module with a Geiger counter that allows the detection of ionizing radiation. It can only detect nuclear, x-ray, cosmic radiation, etc. It cannot detect electromagnetic radiation, such as radiation from microwave ovens, cell phones, or WiFi. In addition, a Geiger counter is a good random number generator and undefined ionization events of high energy particles can provide random entropy. The module is equipped with a Gravity connector and communicates via a digital interface. It is supplied with the voltage from 3.3 to 5 V. Full documentation is available on the product page.
Features
Geiger counter
- Power supply: 3.3 V to 5 V
- Signal output: digital output
- Working voltage: 400V
- Maximum range: 1200 μSv / h
- Dimensions: 107 x 42 mm
Geiger tube M4011
- Working voltage: 380V to 450V
- Background: 25CPM
- CPM ratio: 153.8 CPM / (μSv / h)
- Dimensions: Φ10 mm x 88 mm
Kit contains
- Gravity module: Geiger Counter
- 3-pin Gravity cable
1178727
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
