Category: Temperature sensors

The module with the MCP96L01 amplifier designed to work with a thermocouple type K, J, T, N, S, E, B, or R. It has a screw connection for connecting a thermocouple and communicates via I2C. Adafruit 5165

Module with MLX90614 temperature sensor with a measurement accuracy of 0.2°C and a viewing angle of 35°. The board is equipped with a Grove connector and communicates via the I2C interface. Seeed Studio 101020895

Module for high temperature measurement with a range from -200°C to 700°C dedicated to a probe with a K-type thermocouple. Communication via SPI. SparkFun SEN-13266

Module with the MCP9600 amplifier designed to work with a K-type thermocouple. The module has a screw connector for connecting this type of thermocouple. I2C communication. SparkFun SEN-16295

Temperature and humidity sensor module based on the HTS221 chip. Equipped with a STEMMA QT connector, it communicates via an I2C or SPI interface. Adafruit 4535

Module with sensor TMP117. It enables measurement in the range from –55°C to 150°C with a very high accuracy up to ± 0.1°C. It communicates via the I2C interface. Adafruit 4821

Module with a temperature sensor designed for the M5Stack sets. It allows you to measure high temperatures. The set includes a K-type thermocouple probe. M5Stack U133

Module with the MCP9600 amplifier designed to work with a K-type thermocouple. The module has a PCC connector for connecting this type of thermocouple. I2C communication. SparkFun SEN-16294

Non-contact temperature sensor. Used to measure the infrared intensity of an object to calculate the surface temperature without a contact point in the range -70 ... 380 ° C. DFRobot SEN0256

Non-contact temperature sensor with a measuring range from -70 to 380°C. It uses infrared waves and has a current output. DFRobot SEN0264

Module with MLX90615 temperature sensor with a measurement accuracy of 1°C and a resolution of 0.02°C. The board is equipped with a Grove connector and communicates via the I2C interface. Seeed Studio 101020077

Module with MLX90614 temperature sensor with a measurement accuracy of 0.2°C and a viewing angle of 5°. The board is equipped with a Grove connector and communicates via the I2C interface. Seeed Studio 101020894

Module with a DS18B20 temperature sensor with a measuring range from -55 to 125°C. It communicates via the 1-wire interface

Module with digital temperature sensor TMP102. It enables temperature measurement in the range from –40°C to 125°C with an accuracy of 0.5°C. The system communicates via the I2C interface. SparkFun SEN-16304

A module with a temperature sensor based on the absorption of infrared radiation. Enables non-contact measurement. modTMP006

Module with MLX90614-DCI sensor for non-contact temperature measurement in the range from -70℃ to 270℃. I2C communication. DFRobot SEN0263

The Pmod TMP3 is an ambient temperature sensor built around the Microchip TCN75A. Users may configure the output through I²C to up to 12 bits of resolution as well as setting a trigger to occur when a user defined temperature threshold is reached.. Digilent 410-287

High temperature measuring kit. It consists of a signal conversion module with a range of -270°C to 1372°C and a K-type thermocouple probe with a range of up to 800°C. I2C communication DFRobot DFR0558

The module with the MCP9600 amplifier is designed to work with a thermocouple. The board is equipped with a Grove connector and communicates via I2C. Seeed Studio 101020594

Board with a temperature sensor DS18B20 designed for modules ESP8266, ESP-01 and ESP-01S
