MD30C DC Motor Driver 30A 5V-30V - DC motor controller
ID: 578525
5906623405350
zł142.53
Tax included
zł115.88 tax excl.
Direct current motor driver (DC) with a working voltage from 5 to 30 V and a maximum continuous current of 30 A. It can be controlled by a PWM signal or by means of built-in buttons. Cytron MD30C
Description
Single-channel DC motor driver. It allows you to control the movement of motors with a supply voltage from 5 to 30 V and a current consumption of up to 30 A (continuous current). The control can be done via the PWM signal or using the built-in buttons, which allow very easy testing of the drives without the need to connect a controller. The controller uses components that ensure fast response times. The module can work with 3.3 V and 5 V systems, making it compatible with all popular development boards. In the GitHub repository, the Arduino library is available along with the user manual.
Features
- Single-channel DC motor driver
- The motor supply voltage is from 5 V to 30 V
- Maximum continuous current up to 30 A and instantaneous 80 A
- Control voltage 3.3 V or 5 V
- The components used ensure a quick reaction time
- Screw connection for power and motor connection
- Control buttons
- 3-pin control connector (DIR, PWM, GND)
- Speed control by PWM signal up to 20 kHz
- Dimensions: 93.98 x 78.74 mm
Kit contains
- DC motor driver MD10C R3.0 10A
- 2510 3-pin connector (female)
- 3 x Clamp Pins 2510
- 2 x jumper
578525
Data sheet
- Output current
- 30 A
- Number of channels
- 1
- Supply voltage min
- 5 V
- Supply voltages max
- 30 V
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
